| Engine |
|
|
|
| Configuration |
DOHC, 4 cylinder, 8 valves, YICS, air-cooled. |
Lubrication |
|
| Bore & Stroke |
68.5 x 60.5 mm |
Ignition |
CDI |
| Capacity |
891 ccm (86-93) |
Charging system |
12v |
| Compression Ratio |
|
Starter |
Electric |
| Max Power |
97/9500rpm (83-85) 98(72,1kw)/9000rpm (86-93) |
Transmission |
Shaft drive |
| Max Torque |
8,3kgm/7000rpm (86-93) |
Gearbox |
5 speed |
| Fuel |
4 carbs |
Clutch |
Wet multiplate |
|
|
|
|
| Chassis |
|
|
|
| Frame |
|
Wheels |
18in diecast alloy front & rear |
| Dimensions
Weight
Wheelbase
Length
Seat Height
Ground Clearance
|
218kg
1490mm
2230mm
780mm |
Tyres |
Front 100/90-18
Rear 120/90-18 |
| Front Suspension |
37mm conventional telescopic |
Brakes |
Dual discs front, single disc rear. |
| Rear suspension |
Dual shock absorbers |
Fuel Capacity |
22L |
|
|
|
|
| Performance |
|
|
|
| Top Speed |
|
Fuel Economy |
|
| Acceleration |
|
|
|
|
|
|
|
| Additional Information |
|
|
|
