XT600E 1999 |
 |
| Engine |
|
|
|
| Configuration |
Air cooled 4-stroke single cylinder SOHC 4 valves. Nicalsil bore. |
Gearbox |
5 Speed |
| Bore & Stroke |
95x84 mm (3.74x3.31 in) |
Ignition |
T.C.I. (digital) |
| Capacity |
595 ccm |
Charging system |
12v |
| Compression Ratio |
8.5:1 |
Starter |
Electric |
| Max Power |
43PS(32,2kW)@6500rpm |
Transmission |
45/15 |
| Max Torque |
4,9kg-m(48,1Nm)@5500rpm |
Clutch |
Wet multiplate |
| Fuel |
TK Y26PV |
Lubrication |
Dry sump, SAE 20W40 type SE,
2.5L (2.1 Imp qt, 2.5 US qt) |
|
|
|
|
| Chassis |
|
|
|
| Frame |
27.75° caster, 120mm trail |
Wheels |
|
| Dimensions
Weight
Wheelbase
Length
Seat Height
Ground Clearance
|
156.0 kg
1,440 mm
2,220 mm
855 mm
230 mm |
Tyres |
Front 90/90-21
Rear 120/90-17
Tube type f&r |
| Front Suspension |
Telescopic forks |
Brakes |
Single disc, 282mm
Disc, 220mm |
| Rear suspension |
Mono shock |
Fuel Capacity |
15 L |
|
|
|
|
| Performance |
|
|
|
| Top Speed |
|
Fuel Economy |
|
| Acceleration |
|
|
|
|
|
|
|
| Additional Information |
|
|
|
|
